DS019-K
21 + 1 Thunderbolt 4/USB4 Dock PCBA, aluminum alloy chassis, 40Gbps ultra-fast data transfer, supports single 8K@60Hz or dual 8K@30Hz + 4K@60Hz output. Equipped with 2.5G networking, SD/TF 4.0 card reader, and three audio ports to meet high-performance desktop expansion needs.
Core Features
- Type-C TBT4/USB4 Upstream 40Gbps, Reverse Charging 90W
- DC 20V/7A Power Input
- 2× TBT4/USB4 Downstream 40Gbps, supports 8K@60Hz
- HDMI 2.1 supports up to 8K@60Hz
- 4× Type-C USB 3.2 Gen2 10Gbps
- 4× USB-A 10Gbps + 2× USB-A 480 Mbps
- RJ45 2.5G Ethernet
- SD 4.0 + TF 4.0 High-Speed Card Reader
- 3 × 3.5mm Audio (Mic/Audio Combo)
- Aluminum alloy chassis 130.7×121.7×38.6mm
Typical Use Cases
Professional Workstation
40Gbps bandwidth supports professional video editing and 3D rendering
8K Display
Single 8K@60Hz display or dual high-resolution output
Content Creation
High-speed card reader and multi-port design for photographers and video creators
Premium Office
2. 5G network and rich interfaces boost office productivity
Customizable APIs and capabilities
All APIs and features can be customized to your specific needs. Below are typical configuration options:
- 1× Type-C TBT4/USB4 Uplink (40Gbps, Reverse Charging 90W, DP Alt Mode 1.4)
- 1× DC power input (20V/7A)
- 2× Type-C TBT4/USB4 Downstream (Supports video up to 8K@60Hz)
- 1× HDMI 2.1 (up to 8K@60Hz)
- 4× Type-C USB 3.2 Gen2 (10Gbps, with 1 PD ports supporting up to 1W output)
- 4× USB-A 1 Gbps
- 2× USB-A 480 Mbps
- 1× RJ45 2.5G (backward compatible with 1000/100/10M)
- 1× SD 4.0
- 1× TF 4.0
- 3× 3.5mm Audio (Mic In / Audio Out / Combo)
OEM/ODM Customization
White-label services
Custom Branding, Logos & Packaging Design
Hardware Customization
Interface, port layout, and chassis modifications
Firmware Tuning
Feature Optimization and Custom Development
Authentication Support
CE, FCC, and RoHS regional compliance support
Package Contents
- DS019-K Docking Station
- Thunderbolt 4 Cable
- DC Power Adapter
- User Manual
- Warranty Card
